ISOCOPPO FLAT - HIGH INSULATION TILE-SHAPED SANDWICH PANEL

IsoCoppo Flat is a sandwich panel with the possibility of a high insulating layer characterised by greatly reduced conductivity and transmittance values. Ideal for making lofts in full view such as attics with the possibility of standard finishes in white/grey or wood type.

  1. Pre-painted metal sheet in polyester, steel, aluminium or copper.
  2. High density expanded polyurethane insulating layer
  3. Micro-corrugated flat bottom side in white pre-painted steel, or with wood type finish.
Profile height 51 mm
Total width / useful width 1039 mm / 985 mm
Minimum / maximum length 2100 mm / 13650 mm

(always multiples of 350 mm)

Initial / central / end section 175 mm / 350 mm / 175 mm
Minimum slope 15%
Toolings overlapping
Recommended use roofing
Type of insulating material PUR
Standard insulation thickness (S) 40 mm
Average insulation thickness 65 mm
Other thicknesses (S) 30 – 50 – 60 – 80 mm
Upper support prepainted steel,
 prepainted aluminium
Upper support finishes red tile, antiqued red tile, antiqued sand
Lower support prepainted steel, cardboard felt
Lower support finishes white grey, cherry wood type shade
Fire classification BRoof (T2) according to UNI EN 13501-5:2009, with reference to the harmonised standard UNI EN 14509:2013

fixing on metal

Lateral overlapping

Bottom support in cherry wood type shade

TOP FINISH COLORS

Standard Tile Red

Antiqued tile red

Antiqued sand

BOTTOM SUPPORT FINISH COLORS

In cherry wood type shade

White-Grey
